🔷 Light Pipe Homogenizing Rods

Uniform Light, Compact Form – Precision Light Pipe Manufacturing at Yighen

Light pipe homogenizing rods are critical components used in optical systems to transform non-uniform or patterned light sources—such as LEDs, laser arrays, or arc lamps—into a smooth, evenly distributed output beam. These solid rods use total internal reflection (TIR) to mix and homogenize light spatially and angularly, delivering consistent brightness and beam quality at the output.

At Yighen Ultra Precision, we design and manufacture custom light pipes, integrator rods, and homogenizing bars using high-purity optical materials and ultra-precision machining methods tailored to your wavelength, footprint, and system performance requirements.

🔹 What Is a Light Pipe Homogenizing Rod?

A light pipe is a solid rectangular or cylindrical rod, usually made of optical glass or polymer, designed to:

• Mix spatially inhomogeneous light via multiple internal reflections

• Even out color variations from multi-LED or multi-laser sources

• Shape beam profiles (round to square, square to rectangular, etc.)

• Maintain optical power with minimal loss

Light pipes are commonly used in projection systems, medical illumination, machine vision lighting, and sensing applications that require consistent beam output.

🔹 Shapes & Geometries We Support

We offer input/output face polishing, AR coatings, and edge blackening to improve efficiency and reduce unwanted light scatter.

🔹 Material Options

Yighen offers light pipe rods in a variety of optical materials to suit different spectral regions:

• Optical Glass (BK7, B270, fused silica) – Ideal for visible and UV

• Optical Polymers (PMMA, ZEONEX, TOPAS) – Lightweight, prototyping or low-cost builds

• IR Materials (CaF₂, ZnSe, IR-grade PMMA) – For IR and thermal imaging

• Custom Coatings – AR, HR, or diffusive depending on application

We also support diamond turning of rods for high-precision surfaces, especially in polymer-based systems.

🔹 Applications of Light Pipes

Yighen's homogenizers are especially suited for DLP, LCD, LCoS, and laser-scanning projection systems.

🔹 Precision Manufacturing Capabilities

We produce prototype quantities as well as volume orders, all inspected for optical clarity, dimension, and angular accuracy.

🔹 Why Choose Yighen for Light Pipes?

• ✔️ Full control from design to delivery: In-house machining and polishing

• ✔️ Material matching expertise: Know-how across plastics and optical glass

• ✔️ Custom geometry support: Fast turnaround for one-offs and small batches

• ✔️ Application-driven engineering: We understand real-world lighting challenges

❓ FAQ

Q: Can you simulate beam uniformity before manufacturing?
A: Yes, we offer optical simulations using LightTools or Zemax to validate your design.

Q: Do you offer blackening for the sides of the rod?
A: Yes, sidewall blackening is available to suppress stray light and improve beam contrast.

Q: How fast can I get a prototype?
A: For standard shapes in PMMA or ZEONEX, we can produce samples within 10–15 working days.

🔦 Achieve Uniform Light Distribution with Precision Rods

Yighen offers high-precision light pipe homogenizing rods that deliver uniform illumination for endoscopy, projection, sensing, and machine vision.
We support square, circular, hexagonal, and custom cross-sections — using optical-grade polymers or glass, optimized for TIR and low scattering.

Our expertise covers total length, tapering design, entry coupling optimization, and output face coating — ensuring consistent beam output across various source types.

🔵 Request a Homogenizing Rod Quotation or Design Assistance
📩 Send us your LED source spec, mechanical layout, or target illumination profile — we’ll provide geometry and material suggestions within 24 hours.

—

Need to explore available rod geometries and length specs?
📄 Download Our Light Pipe Capabilities Sheet

Want to learn how we integrate light pipes into custom modules?
👤 More About Yighen
