🌐 Wide Angle Lenses by Yighen

Custom-Designed Lenses for Wide Field Imaging & Projection

👁️ See More with Less Distance

Wide angle lenses are essential in systems where capturing or projecting a broader field of view (FOV) is critical. Whether it's immersive AR/VR display optics, surveillance, machine vision, or automotive imaging, Yighen delivers precision-engineered wide angle lenses that combine low distortion, compact size, and high resolution.

🔍 Core Advantages of Yighen Wide Angle Optics

• 🔭 FOV up to 160° with minimal edge aberration

• 📷 Low distortion: <1% typical (even <0.5% in custom designs)

• 🔬 Multi-element design with aspheric and freeform surfaces

• 🧪 Glass, plastic, or hybrid materials for flexibility & weight control

• ⚙️ Sensor-matched imaging: optimized for 1/4" to 1", 4/3", APS-C formats

• 🌡️ Thermal stability and IP-rated rugged housings available

📐 Key Specifications

🔧 Applications of Wide Angle Lens Modules

📷 Machine Vision & Robotics

Capture wide inspection zones or robotic workspace with low-latency wide FOV lenses.

🚘 ADAS & Automotive Imaging

Enhance lane detection and obstacle awareness with ultra-wide IR-capable optics.

🧠 AR/VR Systems

Compact wide-angle projection and imaging lenses for head-mounted displays.

🏙️ Surveillance & Smart Cities

Monitor broader scenes with fewer cameras; integrate with edge-AI analytics.

🧬 Medical & Endoscopy

Design wide-FOV visualization for non-invasive diagnostics in compact devices.

🛠️ Custom Lens Design & Assembly

Yighen offers end-to-end custom wide angle lens services:

• 📐 Optical design: aspheric/freeform modeling, stray light analysis

• 🧰 Mechanical design: compact barrel, thermal management

• 🧪 Materials: ZEONEX, OKP, COP, glass (infrared-transmitting available)

• ⚙️ Assembly: multi-element cemented or air-spaced designs

• 📊 Testing: distortion, MTF, veiling glare, image circle uniformity

All modules can be integrated with filters, apertures, and ruggedized mounts for field deployment.

🏭 Yighen In-House Capabilities

Our Dongguan facility supports precision wide-angle optics from prototyping to scale-up:

• 🔩 Ultra-precision freeform & aspheric lens machining

• 🧼 Cleanroom assembly (ISO 7) for lens modules

• 📊 Optical metrology: Interferometer, MTF, distortion bench

• ✅ ISO 9001 & ISO 13485 Certified production system

🧪 Case Study: Wide Angle Lens for Smart Agriculture Drone

Client: US-based agri-tech company
Specs: 140° FOV, 1/2.3" sensor, IR-pass filter integrated
Result: Real-time crop imaging with edge detail >80% MTF
Lead Time: 4 weeks prototype to 1K batch delivery

🌐 Expand Your Field of View

Whether for panoramic surveillance, mobile imaging, or machine vision, Yighen’s wide angle lenses are engineered for minimal distortion, sharp edge-to-edge resolution, and compact integration.

📩 Request a Custom Wide Angle Design
Tell us your target sensor size, FOV, lens constraints, and wavelength—we’ll tailor a wide angle solution to match.

📘 Download Datasheets & Assembly Drawings
Access optical specs, distortion graphs, and module dimensions on our Downloads page.

🏢 See What Powers Our Innovation
Visit our About page to learn how we support projects from optical design through full-scale manufacturing.
