Cylindrical lenses are essential components in many advanced optical systems, enabling beam shaping, line focusing, and astigmatic correction. At Yighen Ultra Precision, we specialize in the custom design and manufacturing of cylindrical lenses, offering high-precision prototypes and scalable mass production to meet demanding application needs.

✅ What Are Cylindrical Lenses?

Unlike spherical lenses that focus light in two dimensions, cylindrical lenses focus or expand light in just one axis. This makes them ideal for:

• Laser line generation

• Optical scanning systems

• Bar code readers

• Medical laser systems

• Cylindrical anamorphic optics

• Spectroscopy and interferometry

•

Q: What are optical cylindrical components used for?

A: Optical cylindrical components are commonly used in laser line generation, beam shaping, and scanning applications. Yighen offers custom cylindrical optics with high precision surface quality and fast turnaround times.

🛠 Our Manufacturing Capabilities

Yighen combines world-class equipment with optical manufacturing expertise to deliver high-accuracy cylindrical lenses from both glass and optical plastics. Our capabilities include:

• Ultra-Precision Grinding for Glass Lenses

For materials like BK7, fused silica, quartz, and optical crown glass, we employ high-end Toshiba ULG-100D and ULG-100D(H3) ultra-precision grinding machines. These achieve:

• Form accuracy (P-V): ≤0.030μm

• Surface roughness (Ra): ≤0.01μm

• Diamond Turning for Plastic and IR Materials

We use NanoTech 250, NanoForm 200, and Toshiba ULC-100F(S) for single-point diamond turning (SPDT), ensuring:

• Surface roughness as low as Ra 0.001μm

• Form error under 0.1μm

• Ideal for PMMA, COP, ZEONEX, and CaF₂, MgF₂, Ge, ZnSe

🧩 Customization & Tolerances

Yighen supports fully customized cylindrical lenses based on your optical layout. Our typical specification ranges:

• Focal Length: from 1 mm to 500 mm

• Diameter / Width: 1 mm to 150 mm

• Thickness Tolerance: ±0.02 mm

• Centering Accuracy: <3 arcmin

• Surface Quality: 20-10 to 60-40 (MIL-PRF-13830B)

Optional coatings include AR, BBAR, UV-VIS, and NIR for enhanced performance.

📦 Materials We Support

We work with a wide range of materials to fit your budget and optical requirements:

Glass Materials:

• BK7, Fused Silica, Quartz

• CaF₂, MgF₂, SF11, LaK types

Optical Plastics:

• PMMA, PC, COP, OKP-1, ZEONEX, TOPAS, APEL

Infrared Materials:

• ZnSe, Ge, IR-grade polymers

🔬 Applications of Cylindrical Lenses

Our cylindrical lenses are used in:

• Laser diode collimators

• Line lasers & machine vision

• Industrial laser cutting and welding

• Medical diagnostics & therapy

• Optical data storage and scanning

• Beam shaping for holography and lithography

🏭 Precision at Scale – From Prototype to Mass Production

Whether you're developing a single prototype or scaling to large-volume production, Yighen’s in-house manufacturing and ISO-aligned quality control ensure speed, consistency, and cost-efficiency.

We operate our own factory in Dongguan, China, under our registered Chinese brand 倚光科技 (Yiguang Technology), equipped with over 40 sets of ultra-precision and diamond turning equipment, metrology systems, and coating capabilities. No outsourcing, no compromises.

📈 Why Choose Yighen?

✔ Ultra-precision surface quality
✔ Fast lead times for custom designs
✔ In-house optical engineers for design feedback
✔ One-stop prototyping to mass production
✔ Excellent pricing for OEM/ODM orders

📏 Precision Cylindrical Lenses — Built for Laser & Optical Line Systems

At Yighen, we manufacture precision cylindrical lenses for beam shaping, line focusing, and anamorphic correction — across visible, NIR, and IR bands.

Whether you need plano-convex, bi-convex, or custom toroidal profiles, our ultra-precision grinding and diamond turning platforms ensure tight form accuracy, low surface roughness, and consistent focal performance.

🔵 Request a Cylindrical Lens Quote
📩 Send us your desired focal length, material, and dimensions — we’ll respond within 24 hours.

—

Want to explore our production tolerances, material options, and form specs?
📄 Download Our Cylindrical Lens Capability Sheet

Want to understand our tooling, polishing, and quality control approach?
👤 Learn More About Yighen
