🔩 Opto-Mechanical Modules by Yighen

Integrated Optical Systems for Imaging, Laser & Sensing Applications

🔧 What Are Opto-Mechanical Modules?

Opto-mechanical modules are complete assemblies that integrate optical lenses, mirrors, filters, or lasers with precision mechanical structures such as lens barrels, mounts, housings, and motion systems. These modules are essential in ensuring alignment stability, environmental protection, and performance consistency across varying conditions.

At Yighen, we go beyond single optical components—we deliver application-ready optical subassemblies, from concept to production.

🧠 Why Choose Yighen for Opto-Mechanical Integration?

• 🔩 Full vertical integration: optical design + precision machining + assembly

• 🧪 Mechanical alignment tolerances as tight as ±5 μm

• ⚙️ Thermal & vibration compensation structures

• 🛠️ Designed for shock, vibration, and environmental sealing

• 🎯 AR/VR, medical, defense, laser, and industrial imaging applications

• 📄 Full deliverables: 3D CAD, assembly drawings, test reports, CoC

🔬 Opto-Mechanical Capabilities

🏭 Yighen In-House Manufacturing & Assembly

Yighen maintains a dedicated optical module assembly line in our Dongguan facility, featuring:

• 🔧 CNC-machined precision housings

• 🧬 Cleanroom lens assembly (Class 10,000)

• 🪛 Torque-controlled mechanical fastening

• 🔍 Interferometric + MTF test benches

• 🧾 Component traceability & full inspection

All modules undergo thermal shock, vibration, and optical performance validation before delivery.

📦 Types of Opto-Mechanical Modules We Deliver

🔹 Imaging Lens Modules

For industrial inspection, machine vision, mobile optics
• Fixed or zoom lens groups with focus/iris rings
• Optional SWIR/NIR-compatible variants

🔹 Laser Collimation & Beam Expanders

For laser marking, LIDAR, optical communication
• Precision-aligned lenses + housing
• High-durability coatings for 1064 nm, 1550 nm, 10.6 μm

🔹 Microscopy & Bioimaging Assemblies

Objective holders + tube lens integration
• Custom parfocal & working distance support
• Designed for vibration-free lab environments

🔹 AR/VR Projection Optics

Folded path modules for headsets
• Hybrid lens + mirror or prism structure
• Compact, lightweight, and shockproof

📈 Case Study: Laser Beam Expander Module

Client: EU-based medical laser system manufacturer
Specs: 5X beam expander, 1064 nm, M² < 1.3
Design: Three-element air-spaced lenses + anodized barrel
Result: <3 arcmin beam deviation across –10°C to +60°C
Lead Time: 4 weeks including coating and full validation

🌍 Global Delivery, Local Support

With offices in Hong Kong (HQ), Dongguan (Manufacturing), and Singapore (R&D Precision Lab), we provide end-to-end module delivery from prototyping to volume manufacturing.

🧩 Opto-Mechanical Module Services

• 🧠 Design-for-Assembly (DFA) review & mechanical tolerance budgeting

• 🪛 Precision assembly tooling & jigs

• 🧪 Full-stack testing: MTF, interferometry, environmental chamber

• 🧾 BOM + CoC + assembly flow documentation

• 🔁 Reverse engineering of legacy modules

🧩 Integrated Optics, Simplified

At Yighen, we help you go beyond discrete optics. Our opto-mechanical modules combine lenses, mounts, housings, and alignment features into turnkey subassemblies—designed for performance, manufacturability, and scale.

📩 Request a Custom Module Quote
Submit your optical spec, mechanical constraints, and integration requirements. We’ll co-develop a solution optimized for your system.

📘 Explore Our Full Module Portfolio
From microscope objectives to AR projection engines, explore drawings and datasheets via our Downloads page.

🏢 Why Yighen? See Our Vertical Capabilities
Visit About Us to learn how we unify design, machining, coating, and assembly in-house.
